CONTEC CMS100G – 1 Channel ECG Machine with Touchscreen & Rechargeable Battery

Product Description

The CONTEC CMS100G 1-Channel ECG Machine is a compact, lightweight, and efficient electrocardiograph device designed for single-channel ECG waveform acquisition and analysis. It features a 2.7” LCD touch screen, rechargeable lithium battery, and high-speed thermal printer, making it ideal for portable use in hospitals, clinics, and field environments.

---

Applications

• ECG waveform acquisition and printing

• Outpatient and bedside heart rhythm monitoring

• Field medical use due to portable design

---

Power Supply

• AC Input: 100V–240V, 50/60Hz

• DC Input: 7.4V, 3700mAh rechargeable lithium battery

• Battery backup time: Approx. 4 hours

---

Interface

• 2.7” Touch Screen LCD

• USB port for data transfer (optional basic software)

---

Voltage & Calibration

• Patient leakage current: ≤10μA

• Calibration Voltage: 1mV ± 0.2mV

• Standard sensitivity: 10mm/mV ± 0.2mV

---

Signal & Noise

• CMRR: ≥ 60dB, ≥ 100dB (with filter)

• Frequency Response: 0.05Hz – 150Hz (±3dB)

• EMG filter: 35Hz (±3dB)

• Noise level: ≤15μVp-p

---

Performance

• Sampling rate: 1000Hz

• High-speed thermal printer

• Storage: Stores more than 100 patients’ data

• Input: Floating and defibrillator-protected

---

Lead System

• 12-lead ECG

• Digital signal processor

• Printing Modes:

  • 4*3

  • Auto 3*4 +1

  • Auto 3*4

  • Auto 2*6 +1

  • Auto 2*6

  • Auto 3-2+1

  • Rhythm 1, 2

  • Manual mode

---

Dimensions & Weight

• Machine Size: 315mm (L) x 215mm (W) x 77mm (H)

• Net Weight: Approx. 1.5 kg

---

Accessories Included

• Power cable

• Patient lead wires

• Thermal recording paper

• User manual

---

Certifications

• CE Certified

• FDA Approved

---

Warranty & Support

• 1-year manufacturer warranty

• Service support available in UAE

---

Usage Type

• Clinical ECG recording

• Portable use for home visits and mobile screening
